Features:
● Made of stainless steel, beautiful appearance
● Windows are made of strong tempered flat glass
● Protection class IP66
● Indoor and outdoor installation, all-weather use
● With active infrared irradiation function
● High-quality infrared light-emitting diodes, large light flux and long service life
● Infrared wavelength 850nm
● It can be turned on or off automatically according to the ambient light
- certified Explosion-proof mark ExdⅡCT6 GB/tD A21 IP66 80℃ Electrical indicators
- Input voltage 12VDC
- Working current ≤2A
- Power consumption ≤20W
- Infrared lamp projection distance 80 meters optional
- Wavelength 850nm
- Material Stainless steel 304 or 316L
- Protection class IP66
- Window transparent part Thickness 8mm
- Number of outlet holes 1
- Outlet hole thread specification G-3/4”
- Installation method Electric pan/tilt, semi-fixed pan/tilt, fixed bracket
- Image sensor 1/3 inch CMOS
- Number of pixels 1280(H)*960(V)
- Day and night function Support IR-CUT electromagnetic switching
- Illumination 0.01Lux/F1.2 (color mode), 0.001Lux/F1.2 (black and white mode)
- Signal to noise ratio above 50dB
- Gain Control Manual/Automatic
- White Balance Manual/Automatic
- Electronic shutter manual/automatic (adjustable range, 1/3~1/10000)
- Video compression standard H264/MJPEG/JPEG
- Maximum resolution Main stream 1280*960, auxiliary stream 704*576
Video frame rate main stream (1280*960@15fps), auxiliary stream (704*576@15fps)
Main stream (1280*720@25fps), auxiliary stream (704*576@25fps) - Video bit rate 48k~8Mbps bit rate adjustable, also can be customized
- Wired network 1 channel 10/100M Ethernet, RJ45 interface
- Network protocol HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, SNMP, QoS, UPnP, NTP
- Access Protocol Standard ONVIF
- Weight 7Kg
Brochure : https://tinyurl.com/ALBox-EXC221
