Features
- Portable and easy/quick installation
- Advanced linear CCD scanning technology
- High-resolution complete color image of under the vehicle
- Weatherproof scanning unit (IP68 the highest level)
- Anti-fog function
- Multilingual Graphical User Interface(GUI)
- Option: Automated License Plate Reader(ALPR)
- Maximum scanning rate: 18kHz
- Vehicle speed: 1-60 km/h, recommend < 30 km/h
- View angle: 170 degrees
- Scanner data line: 10 meters(length customizable)
- Lighting: 160W
- Lighting components: 2 single sealed LED surface light sources, life 50000h
- Load-bearing weight : 30T
- Waterproof grade : IP68 (the highest level)
- Weight of the scanning device : 28kg
- Size of the scanning device : 450x400x88mm
A. Under vehicle image display area: real-time display of vehicles at the detected image, historical images, and bottom of the vehicle underbody after treatment images.
B. Live video area: Via external plate camera, display video which is automatically capture vehicle license plate images when the vehicle passing the detection zone.
C. License plate number information display area: Displaying the detected vehicle license plate capturing photos with automatic identification of the results. click [Modify] button can modify the number of recognition errors.
D. Vehicle information list: Checking vehicle information in all day, including license plate number, the checking time, vehicle surveillance results.
E. Real-time log information list: real-time display of the region need to run the process produces some log information to facilitate the use of personnel or maintenance personnel system view real-time operation of the system state.
F. Image manipulation functional areas: the image to zoom; brighten, darken; edge enhancement, super-enhanced operation.
G. Functional operating areas: the license plate camera and used to set the relevant parameters linear array camera, as well as the system language, real-time curve, historical data query functions.
- Technology : Linear array CCD scan technology and dynamic imaging of BW/color
- Scanning resolution : = 2048 pixels CCD / = 4096 pixels CCD
- Imaging speed : <1 second
- Image display mode : Large-format horizontal display
- Image storage format : Standard BMP or JPEG
- System interface language : can be customized
- Image data transmission : network RJ45
- Scene image display : =1 channel
- Image search : Retrieve the image by date, time, license plate number, and images.
- Image resolution : 12000 × 6144
- Automatic scan : Display the image in 1s after the vehicle passes at a speed of 1-65km/h
Automatic image storage Save no less than 10,000 pictures and delete the expired pictures automatically
- Imaging function : Adjust saturation, contrast, balance and sharpening, zoom in and out (1-16), and local enlargement
- Monitor One 22-inch true color LCD monitor
- Console A console which can lock the display and keyboard
- CPU Intel Core Quad-Core Processor
- RAM DDR3, greater than 2GB
- Hard Disk 500G High Speed Hard Disk
- Graphics Card: DDR3, 192BIT Independent Graphics Card
- Platform Windows XP/ Windows 7
- Operating temperature : -25°C ~ 60°C
- Storage temperature : -40°C ~ 75°C
- Power supply : AC110-240V 50~60Hz ±3Hz
