Features
- Built-In a reader and an external reader port for exit or anti-pass-back function
- Alarm function is available (tamper, Force entrance, Door open too long and Duress)
- RF Frequency: 125KHz
- Built-In a reader and an external reader port for exit or anti-pass-back function
- Alarm function is available (tamper, Force entrance, Door open too long and Duress)
- RF Frequency: 125KHz
- Input Voltage: 12V DC
- Temp. Switch: Limit Switch (Form C)
- Aux. WG Port: WG 26/34
- Environment: -20˚ C to 75˚ C
- Anti-pass-back: 1024 (with Aux. reader)
- Lift Control: 32 stops/1024 users
- DI Input: Egress bottom/door sensor
- Dimension (mm): 112 x 76 x 25
